Carbon Smart Indoor Sauna Room Kit – 8' x 9' x 8'

Overview

The Carbon Smart™ Indoor Sauna Room Kit – 8' x 9' x 8' is a complete interior sauna package designed for residential or commercial indoor sauna installations. The kit includes pre-cut interior components, Thermo Poplar wall and ceiling boards, benches, an all-glass sauna door, ventilation components, lighting, and sauna accessories.

The kit is designed to simplify sauna room construction while allowing the surrounding structure to be prepared separately. Customers provide the framing, insulation, electrical wiring, and exterior wall covering, while the Carbon Smart™ kit supplies the specified interior sauna components.

With a recommended ceiling height of 8 feet, customizable bench configurations, and several compatible Harvia heater options, the kit can be configured for different room layouts and installation requirements.

Key Features

• 8' x 9' x 8' Sauna Room Kit – Designed for an indoor sauna room with an 8-foot recommended ceiling height.
• Thermo Poplar Interior – Features thermally modified Thermo Poplar wood for the walls, ceiling, benches, moldings, and duckboard flooring.
• Pre-Cut Interior Components – Interior components are cut and prepared for the specified room dimensions.
• Customizable Bench Configurations – Choose from available bench layouts shown with the product options.
• All-Glass Sauna Door – Includes a glass door with wood handles and trim.
• Foil Vapor Barrier – Included as part of the sauna room interior package.
• Ventilation Components – Includes upper and lower vent grills.
• Sauna Accessories Included – Includes a bucket with liner and ladle, thermometer, headrest, and marine-grade vapor-proof sauna light.
• Fold-Free Fixed Installation – Designed as a permanent indoor sauna room installation rather than a portable sauna.
• Installation Instructions – Detailed instructions are included to assist with assembly.
• Harvia Heater Options – Multiple WiFi-enabled Harvia heater configurations are available.

Thermo Poplar Construction

The Carbon Smart™ sauna kit uses thermally modified Thermo Poplar throughout key interior components. The wood is thermally modified at approximately 374°F and is described by the manufacturer as undergoing a chemical-free modification process.

Thermal modification changes the properties of the wood and is intended to improve dimensional stability when exposed to changes in indoor temperature and humidity. The resulting wood has a warm, natural appearance suitable for sauna interiors.

The Thermo Poplar components include:

• 1×4 tongue-and-groove wall boards
• 1×4 tongue-and-groove ceiling boards
• Clear 1×4 bench boards
• Bench supports
• Corner moldings
• Wall, ceiling, and baseboard trim
• Duckboard flooring

What's Included

The Carbon Smart™ Indoor Sauna Room Kit includes:

• Foil vapor barrier
• Thermo Poplar ergonomic backrests
• 1×4 tongue-and-groove wall boards
• 1×4 tongue-and-groove ceiling boards
• Clear 1×4 Thermo Poplar bench boards
• Bench supports
• 20-inch-deep benches, custom-built according to the selected configuration
• Thermo Poplar corner moldings
• All-glass sauna door
• Wood door handles and trim
• Thermo Poplar duckboard flooring
• Upper and lower vent grills
• Traditional sauna bucket with liner and ladle
• Sauna thermometer
• Headrest
• Marine-grade wall-mount vapor-proof sauna light
• Detailed installation instructions

Sauna Door Specifications

The included all-glass sauna door has the following dimensions:

• Frame: 27.2" × 78.7" (690 × 2000 mm)
• Glass: 24.4" × 77.3" (620 × 1963 mm)
• Frame Thickness: 1.65" × 3.6" (42 × 92 mm)
• Required Rough Opening: 28" × 80"

Important: The standard shipment includes an all-glass door. Product images may show a glass wall for illustrative purposes, but the included door is the all-glass door specified above.

Bench Configurations

Several bench configurations are available to accommodate different interior layouts. The available configurations are shown in the product images and are built using 20-inch-deep clear Thermo Poplar bench boards with supports.

The included backrests are shipped flat. If an angled backrest is preferred, spacers can be created during installation to achieve the desired angle.

Installation Requirements

The Carbon Smart™ kit supplies the specified interior sauna components, but the installation requires preparation of the surrounding room.

Customers are responsible for providing:

• Structural framing
• Insulation
• Electrical wiring
• Exterior wall covering

The manufacturer recommends an 8-foot ceiling height for the sauna installation. Contact the manufacturer or seller before ordering if a custom ceiling height is required.

Wall boards are installed in the standard horizontal direction. If the room width exceeds 8 feet, an interior seam will be incorporated where two boards meet to span the additional width.

Harvia Heater Options

The sauna kit can be configured with several Harvia WiFi-enabled heater options. Heater specifications vary by model.

Harvia Cilindro 11KW WiFi

• Power Output: 11 kW
• Brand: Harvia
• Control Type: WiFi Control
• WiFi Connectivity: Yes
• Heater Stones Included: Yes
• Railing Included: No
• Combi Steam Function: No
• Model Series: Cilindro Series
• Model: Cilindro
• Remote Control: App-based via WiFi

Harvia Club 10KW WiFi

• Power Output: 10 kW
• Brand: Harvia
• Control Type: WiFi Control
• WiFi Connectivity: Yes
• Heater Stones Included: Yes
• Railing Included: No
• Combi Steam Function: No
• Model Series: Club Series
• Model: Club
• Remote Control: App-based via WiFi

Harvia Virta 10.5KW WiFi with Railing

• Power Output: 10.5 kW
• Brand: Harvia
• Control Type: WiFi Control
• WiFi Connectivity: Yes
• Heater Stones Included: Yes
• Railing Included: Yes
• Combi Steam Function: No
• Model Series: Virta Series
• Model: Virta
• Remote Control: App-based via WiFi

Harvia Virta Combi 10.5KW WiFi with Railing

• Power Output: 10.5 kW
• Brand: Harvia
• Control Type: WiFi Control
• WiFi Connectivity: Yes
• Heater Stones Included: Yes
• Railing Included: Yes
• Combi Steam Function: Yes
• Model Series: Virta Combi Series
• Model: Virta Combi
• Remote Control: App-based via WiFi

Heater Comparison

Feature	Harvia Cilindro 11KW	Harvia Club 10KW	Harvia Virta 10.5KW	Harvia Virta Combi 10.5KW
Power Output	11 kW	10 kW	10.5 kW	10.5 kW
WiFi Connectivity	Yes	Yes	Yes	Yes
App-Based Remote Control	Yes	Yes	Yes	Yes
Heater Stones Included	Yes	Yes	Yes	Yes
Safety Railing	No	No	Yes	Yes
Combi Steam Function	No	No	No	Yes
Model Series	Cilindro	Club	Virta	Virta Combi

The Virta Combi is the only option in this lineup listed with a built-in combi steam function. The Virta and Virta Combi models include a protective railing, while the Cilindro and Club options do not.

Who It's For

The Carbon Smart™ Indoor Sauna Room Kit is suitable for homeowners, contractors, spas, gyms, hospitality spaces, and commercial facilities planning a permanent indoor sauna installation. It is particularly useful for projects where a pre-cut Thermo Poplar interior package, customizable bench layout, glass door, ventilation components, lighting, and sauna accessories are needed in one kit.

Important Product Notes

• The listed kit is for an 8' × 9' × 8' indoor sauna room.
• An 8-foot ceiling height is recommended.
• Framing, insulation, electrical wiring, and exterior wall covering are not included.
• The standard shipment includes an all-glass sauna door.
• Product images showing glass walls may be for illustration only.
• Bench configurations vary according to the selected option.
• Backrests are shipped flat and may be angled during installation using appropriate spacers.
• Custom ceiling heights should be confirmed before ordering.
• Wall boards are normally installed horizontally; rooms wider than 8 feet may require an interior seam.
